Removing the LCD Brackets and FPC Cable 1. See “Removing the LCD Panel” on page 104. 2. Turn the LCD Panel over on a clean surface, and lift the cable as shown to detach the adhesive.
3. Grip the adhesive strip covering the LCD cable connector and pull it back (1). 4. Remove the cable from the panel as shown (2).
1
2 5. Remove the six securing screws (three on each side) from the LCD Panel brackets in numeric order, from 3 to 1.
3
1 2
2 1
3
Step LCD Brackets
Size M2*3
Quantity
Screw Type
6
6. Remove the LCD brackets by pulling them away from the LCD Panel.
