TRANSHEALTH™ Report Screen Buttons • Load—loads and displays a saved reports. • Delete—deletes a displayed report from the save listing. • Save—saves a new report. • Print—prints a displayed report. • Close—exits the TRANSHEALTH™ feature, DOES NOT save a displayed report.
Loading Saved TRANSHEALTH™ Reports To load a saved report, Allison DOC™ For PC–Service Tool must not be connected to a transmission or playing back a snapshot. This feature is only available for users with Reprogramming enabled. 1. Select the TRANSHEALTH™ Report option from the Reports drop-down menu or click the F2-TRANSHEALTH™ button, or press the F2 key. The TRANSHEALTH™ dialog box is displayed
2. Select the saved TRANSHEALTH™ report from the Select One drop-down menu. 3. Click on the Load button. 4. The saved TRANSHEALTH™ report is displayed.
