3. If you want to continue, click YES. 4. The tool starts reprogramming the wires. A red status bar is displayed at the bottom of the TCM Reprogramming window. 5. A window is displayed indicating the wires were successfully reprogrammed.
6. Click OK. 7. The tool continues the process of reprogramming the CMCs. A red status bar is displayed at the bottom of the TCM Reprogramming window. NOTE: If the service tool receives an error message from the TCM (for example a CMC value is out-of-range), a window (describing the problem) will be displayed, and the service tool re-displays the reprogramming screen. 8. A window displays indicating the CMCs were successfully reprogrammed.
9. Click OK.
Reprogramming Status for WTEC II, WTEC III, and CEC2 During the reprogramming function, a status line displays at the bottom of the reprogramming window. 78
