NOTE: The “Connect to the data bus with a new connection.” option should only be selected if the user wants to use the Data Bus Viewer (monitor the data bus) with a different physical translator device.
Playing Back Data Bus Viewer Files The following steps describe how to playback the files saved with the Data Bus Viewer: 1. Select Data Bus Viewer from the File menu, or the Transmission Connect/Disconnect dialog box—the Data Bus Viewer Configuration window displays. .
2. Select “Playback Data Bus Viewer Files” and click OK. The Data Bus Viewer window displays.
3. Click on the “Select One” pull-down menu, and select the file you want to playback. 56
