Print Screen • Prints the displayed screen
Button and Keyboard Shortcuts The following buttons are always available in the primary Allison DOC™ For PC– Service Tool window. Clicking the button or pressing the associated function key displays the listed menu. F1–Help • Accesses the Help system F2–TRANSHEALTH™ • Displays the TRANSHEALTH™ feature. Refer to Section 7–2 for more detailed information. F3–DTC Lookup • Displays the Trouble Code Lookup window for various control systems F4–Connect (or F4-Disconnect) • Connect (F4-Connect) to or disconnect (F4-Disconnect) from an ECU or TCM F5–Trigger Recording • Triggers the recording session of a snapshot and also inserts a trigger point in the data stream. This constitutes the faster way to initiate a snapshot recording session. • If used during a recording session, inserts “bookmarks” in the data stream of the log file. Bookmarks are sequentially numbered by the system when F6– Bookmark # is used. F6–Stop Recording • Stops a snapshot recording. Accelerator Keys—On screen buttons have shortcuts known as accelerator keys. An underlined character in the button text identifies the button’s accelerator keyboard key. Pressing the accelerator key activates the function associated with the button. For example, on the button below, the P keyboard key is the accelerator key. Dropdown menu items accelerator keys require pressing ALT before pressing the accelerator key. After pressing the ALT/ACCELERATOR KEY combination that menu displays.
When this button is visible, press ALT+ P to activate a print function.
17
