Menus The menu bar at the top of the Allison DOC™ For PC–Service Tool window, above the Status bar, displays the following drop-down menus: File • TCM Reflash (PCCS)—Opens up the TCM Reflash (PCCS) application, only if it’s installed in the PC. • Data Bus Viewer—Opens up the Data Bus Traffic Viewer. This option is disabled during a live connection of the tool. • Exit—Exits the Allison DOC™ For PC–Service Tool program Reprogram • When enabled, displays the TCM/ECU Reprogramming section. Users need special training to enable this section of the tool. Action Items • Clutch Test Enabled—For Allison 4th Generation Control systems and 1000/2000 (Pre-Allison 4th Generation Controls) systems, it displays the Clutch Test floating tool bar. For all other control system (i.e. WTEC II, WTEC III, and CEC2), it controls the Clutch Test mode. • Solenoid Test…—Displays the Solenoid Test screen (not available for WTEC II/III, CEC1, and CEC2). • Reset Adaptive Shift Parameters—(not available for WTEC II/III, CEC1, and CEC2) Displays the Reset Adaptive Shift Parameters window, where transmission adaptive data can be reset to factory values per shift. • Reset Unadapted Shifts—(only available for WTEC II and WTEC III) Resets all transmission adaptive data to factory values. • Reset Fast Adaptive—(not available for 1000/2000 Pre-Allison 4th Generation Controls and CEC2 systems) Activates the Fast Adaptive logic in the TCM/ECU. • Reset Full Throttle Calibrations (TPS only)—(not available for WTEC II, WTEC II, and CEC2 control systems) Resets upper limit of the TPS calibration. • Reset Closed Throttle Calibrations (TPS only)— (not available for WTEC II, WTEC II, and CEC2 control systems) Resets the lower limit of the TPS calibration. • Reset Throttle Calibration—(only available for WTEC II, WTEC III, and CEC2) Resets the throttle position sensor calibration. • Transmission Fault Lamp Test—(only available for Allison 4th Generation Controls systems) Enables the transmission Fault Lamp Test. 14
