To reset full throttle calibration: 1. Select the Action Request drop-down menu. 2. Select Reset Open Throttle Calibration—the Throttle Action window display
3. Fully depress the throttle. 4. Click OK—the Reset Open Throttle Calibration Successful window displays. To reset closed throttle calibration: 1. Select the Action Request drop-down menu. 2. Select Reset Closed Throttle Calibration—the Throttle Action window displays. 3. Do not depress the throttle. 4. Click OK—the Reset Closed Throttle Calibration Successful window displays.
Clutch Test The Clutch Test uses a software tool bar to command a particular range. Fourth and Fifth range are inhibited if the engine speed is above 1400 rpm and Output Speed is 0 rpm. Enable a Clutch Test by: 1. Selecting Drive (D) on the transmission shift selector. 2. Selecting the Action Request drop-down menu. 3. Selecting Clutch Test—the Clutch Test Tool Bar displays with the current range highlighted.
4. To select a range from the Clutch Test Tool Bar, click on the desired range. When the shift or range change is accomplished, the selected number is highlighted. 5. Disable the Clutch Test by closing the Clutch Test window. 102
