Removing the Volume Control Board 1. See “Removing the Upper Cover” on page 81. 2. Open the locking latch on the FFC and disconnect it from the Media Board.
3. Open the locking latch on the FFC and disconnect it from the Volume Control Board.
4. Remove the two screws securing the board to the Upper Cover.
Step Volume Control Board
86
Size M2*3
Quantity
Screw Type
2
Chapter 3
