Removing the Optical Drive Module 1. See “Removing the Lower Door” on page 59. 2. Remove the single screw securing the ODD Module.
Step ODD Module
Size M2.5*4
Quantity
Screw Type
1
3. Insert a suitable object in to the Lower Cover to push the ODD Module clear of the casing. 4. Pull the ODD Module out of the chassis.
60
Chapter 3
