DOS Flash Utility Perform the following steps to use the DOS Flash Utility: 1.
Press F2 during boot to enter the Setup Menu.
2.
Select Boot Menu to modify the boot priority order, for example, if using USB HDD to Update BIOS, move USB HDD to position 1.
Information
Main
Phoenix SecureCore(tm) Setup Utility Security Boot Exit Item Specific Help
Boot priority order: 1. 2. 3. 4. 5. 6. 7. 8.
IDE HDD: Toshiba MK5055GSX-(S1) IDE HDD: WDC WD1600BEVT-22ZCT0-(S5) IDE CD: HL-DT-ST DVDRAM GT20N-(S2) PCI LAN: MBA v11.4.1 Slot 0600 USB HDD: USB CDROM: USB FDC: USB KEY:
Use < > or < > to select a device, then press <F5> to move it down the list, or <F6> to move it up the list. Press <Esc> to escape the menu
Excluded from boot order:
F1 Help ESC Exit 3.
Select Item Select Menu
F5/F6 Enter
C h a n g e Va l u e s Select SubMenu
F9 F10
Setup Default Save and Exit
Execute the FLASH.BAT batch file to update BIOS.
The flash process begins as shown.
44
Chapter 2
