Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the USB diskette drives, the onboard hard disk drive and the DVD drive in the module bay. Select Boot Devices to select specific devices to support boot.
Information
Main
Phoenix SecureCore(tm) Setup Utility Security Boot Exit Item Specific Help
Boot priority order: 1. 2. 3. 4. 5. 6. 7. 8.
IDE HDD: Toshiba MK5055GSX-(S1) IDE HDD: WDC WD1600BEVT-22ZCT0-(S5) IDE CD: HL-DT-ST DVDRAM GT20N-(S2) PCI LAN: MBA v11.4.1 Slot 0600 USB HDD: USB CDROM: USB FDC: USB KEY:
Use < > or < > to select a device, then press <F5> to move it down the list, or <F6> to move it up the list. Press <Esc> to escape the menu
Excluded from boot order:
F1 Help ESC Exit
Chapter 2
Select Item Select Menu
F5/F6 Enter
C h a n g e Va l u e s Select SubMenu
F9 F10
Setup Default Save and Exit
41
