Hardware Specifications and Configurations Processor Item
Specification
CPU
Intel Penryn Dual Core/Quad Core
Type
2.0GHz ~ 2.93GHz CPU
Core Logic
•
Intel GMCH GM45
•
ICH9-M (South Bridge)
•
REALTEK ALC889X for High Definition Audio Codec
CPU Package
uFCPGA-478
Power
Vcca 1.5V, Vccp 1.05V
On-die Cache
3MB or 6MB L2 cache
Front Side Bus
667/800/1066 MHz
Thermal IC
Digital thermal sensor (DTS)
Processor Specifications Item
CPU Speed
Cores
Bus Speed
Mfg Tech
Cache Size
P7350
2.0 GHz
2
1066
45nm
3 MB
478-pin Micro-FCPGA
25
KC.73501.DPP
P7450
2.13 GHz
2
1066
45nm
3 MB
478-pin Micro-FCPGA
25
KC.74501.DPP
P8700
2.53 GHz
2
1066
45nm
3 MB
478-pin Micro-FCPGA
25
KC.87R01.DPP
P9500
2.53 GHz
2
1066
45nm
6 MB
478-pin Micro-FCPGA
25
KC.95E01.DPP
T6400
2.0 GHz
2
800
45nm
3 MB
478-pin Micro-FCPGA
35
KC.64001.DTP
T6600
2.2 GHz
2
800
45nm
2 MB
478-pin Micro-FCPGA
35
KC.66001.DTP
T9550
2.66 GHz
2
1066
45nm
6 MB
478-pin Micro-FCPGA
35
KC.95501.DTP
T9600
2.8 GHz
2
1066
45nm
6 MB
478-pin Micro-FCPGA
35
KC.96E01.DTP
T9800
2.93 GHz
2
1066
45nm
6 MB
478-pin Micro-FCPGA
35
KC.98E01.DTP
Package
Power (W)
Acer P/N
Q9000
2.0 GHz
4
1066
45nm
6 MB
478-pin Micro-FCPGA
45
KC.90001.QQP
P7550
2.26 GHz
2
1066
45nm
3 MB
478-pin Micro-FCPGA
N/A
KC.75501.DPP
T6500
2.1 GHz
2
800
45nm
2 MB
478-pin Micro-FCPGA
N/A
KC.65001.DTP
P8800
2.66 GHz
2
1066
45nm
3 MB
478-pin Micro-FCPGA
25
KC.88R01.DPP
CPU Fan True Value Table Fan On Temp (°C)
16
Fan Speed (rpm)
SPL Spec (dBA)
45
2350
31
55
2600
34
75
3150
38
95
3500
40
•
Throttling 50%: On=105°C, Off=85°C
•
OS Shutdown: 110°C
•
H/W Shutdown: 110°C
Chapter 1
