7.
Plug in AC, keeping the HW Gap shorted, and press Power Button to power on the system till BIOS POST finish. Then remove the tool from the HW Gap.
8.
Restart system. Press F2 key to enter BIOS Setup menu.
If there is no Password request, the BIOS Password has been successfully cleared. Otherwise, please follow the steps and try again. NOTE: The steps are only for clearing BIOS Password (Supervisor Password and User Password).
BIOS Recovery by Crisis Disk BIOS Recovery Boot Block: BIOS Recovery Boot Block is a special block of BIOS. It is used to boot up the system with minimum BIOS initialization. Users can enable this feature to restore the BIOS firmware to a successful one once the previous BIOS flashing process failed.
BIOS Recovery Hotkey: The system provides a function hotkey: Fn+Esc, for enable BIOS Recovery process when system is powered on during BIOS POST. To use this function, it is strongly recommended to have the AC adapter and Battery present. If this function is enabled, the system will force the BIOS to enter a special BIOS block, called Boot Block.
Steps for BIOS Recovery by USB flash crisis disk: Before doing this, prepare the Crisis USB key. The Crisis USB key could be made by executing the Crisis Disk program in another system with Windows XP OS. Follow the steps below: 1.
Plug in the USB disk.
2.
Launch the wincris.exe program to create a USB Crisis Disk. Click Start to initiate the process.
3.
Select the Quick Format option to format the disk and click Start. Follow the instructions on the screen to create the disk.
4. Copy the KAYF0X64.fd BIOS file into USB flash disk root directory. NOTE: Do not place any other *.fd file in the USB flash disk root directory. To use the Crisis USB key, do the following: 1.
Plug USB storage into USB port.
2.
Press Fn + ESC button then plug in AC power. The Power button flashes orange once.
3.
Press Power button to initiate system CRISIS mode. When CRISIS is complete, the system auto restarts with a workable BIOS.
4.
214
Update the latest version BIOS for this machine by regular BIOS flashing process.
Chapter 5
