Replacing the Power Board 1. Slide the Power Board under the retaining clip in the Switch Cover and set it in place, taking care to align the screw holes.
2. Insert the three screws to secure the Power Board to the Switch Cover.
Step Power Board
Size M2.5*4
Quantity
Screw Type
3
1. Connect the FFC from the Power Board and close the locking latch.
Chapter 3
183
