Removing the LCD Panel 1.
See “Removing the Flush LCD Bezel Cap” on page 125.
2. Remove the nine screws securing the LCD Panel to the cover.
NOTE: The six bracket screws are numbered from 1 to 3 on each bracket. Remove the screws in reverse order from 3 to 1.
3
3 1
2 1
Step
Size
Quantity
LCD Panel (red callout)
M2.5*4
8
LCD Panel (green callout)
M2*3
1
Chapter 3
2
Screw Type
129
