Removing the Standard LCD Bezel 1.
See “Removing the LCD Module” on page 78.
2. Remove the four screw caps and screws from the LCD Bezel.
Step
Size
Quantity
Standard LCD Bezel (red callout)
M2.5*4
2
Standard LCD Bezel (green callout)
M2.5*5
2
Screw Type
3. Starting from the inside bottom edge, pry the Bezel away from the panel. Move along the bottom edge toward the hinges as shown.
