Removing the Speaker Module 1. See “Removing the Mainboard” on page 103. 2. Remove the six screws securing the Speaker Module in place. NOTE: The screws securing the Speaker Module in place are cushioned by rubber washers. Ensure that the washers are replaced before replacing the screws.
Step Speaker Module
Size
Quantity
Screw Type
6
3. Using both hands, lift the Speaker Module upward to remove it from the Lower Cover.
