Removing the Finger Print Reader Bracket 1. See “Removing the Upper Cover” on page 81. 2. Remove the two screws securing the bracket to the Upper Cover.
Step Finger Print Reader Bracket
Size M2*3
Quantity
Screw Type
2
3. Rotate the bracket away from the Upper Cover and remove it as shown.
Chapter 3
93
