LCD Module Reassembly Procedure Replacing the MIC and WiFi Antennas 1. Place the Microphone Module in the LCD Module as shown.
2. Run the cable as shown and secure it using the adhesive tabs.
3. Replace the left and right antennas as shown. Press down on the adhesive pads to secure the antennas in place.
4. Replace the left antenna cable (white) as shown. Ensure that the cable is inserted along the cable channel as shown.
Chapter 3
5. Replace the right antenna cables (black) as shown. Ensure that the cables are secured in the cable guides.
85
