Removing the LCD Panel 1. See “Removing the Camera Module” on page 79. 2. Disengage the various cables from the hinges. 3. Remove the four (4) securing screws from the LCD Panel.
Step LCD Panel
Size M2.3*3
Quantity
Screw Type
4
4. Lift the LCD Panel clear of the module as shown.
80
Chapter 3
