Removing the USB Board 1. See See “Removing the Upper Cover” on page 58. 2. Remove the single securing screw from the USB Board.
Step USB Board
Size M2.5*4L
Quantity
Screw Type
1
3. Release the FFC latch and remove the FFC cable from the mainboard connector.
4. Release the FFC latch and remove the FFC cable from the USB connector.
