Main The Main screen allows the user to set the system time and date as well as enable and disable boot option and recovery.
Information
Main
InsydeH20 Setup Utility Power Boot Exit
Security
R e v. 3 . 5 Item Specific Help
S y s t e m Ti m e : System Date: To t a l M e m o r y : Vi d e o M e m o r y :
[19:10:59] [01/22/2010] 2048 MB 32 MB
Quick Boot Network Boot F12 Boot Menu D2D Recovery S ATA M o d e
[Enabled] [Enabled] [Disabled] [Enabled] [AHCI]
F1 Help ESC Exit
Select Item Select Menu
F5/F6 Enter
This is the help for the h o u r f i e l d . Va l i d r a n g e is from 0 to 23. INCREASE/REDUCE: F 5 / F 6
C h a n g e Va l u e s Select SubMenu
F9 F10
Setup Default Save and Exit
NOTE: The screen above is for your reference only. Actual values may differ. The table below describes the parameters in this screen. Parameter
Description
Format/Option
System Time
Sets the system time. The hours are displayed with 24hour format.
Format: HH:MM:SS (hour:minute:second)
System Date
Sets the system date.
Format MM/DD/YYYY (month/day/year)
Total Memory
Displays the total memory available.
N/A
Video Memory
Displays the available memory for Video.
N/A
Quick Boot
Allows startup to skip certain tests while booting, decreasing the time needed to boot the system.
Option: Enabled or Disabled
Network Boot
Enables, disables the system boot from LAN (remote server).
Option: Enabled or Disabled
F12 Boot Menu
Enables, disables Boot Menu during POST.
Option: Enabled or Enabled
D2D Recovery
Enables, disables D2D Recovery function. The function allows the user to create a hidden partition on hard disc drive to store operation system and restore the system to factory defaults.
Option: Enabled or Disabled
SATA Mode
Control the mode in which the SATA controller should operate.
Option: AHCI or IDE
