Item Features
Specification •
98dB Signal-to-Noise Ratio (A-weighting) for DAC output
•
90dB Signal-to-Noise Ratio (A-weighting) for ADC input Internal Digital
•
Power support: 3.3V digital core power; 1.5V~3.3V digital IO power for HDA link; 3.0V~5.0V analog power; 3.0V~5.0V power stage voltage
•
Microphone Acoustic Echo Cancellation (AEC), Noise Suppression (NS), and Beam Forming (BF) technology for voice application
•
Stereo Bridge-Tied Load Class-D amplifier at port-D has 2Watt (rms)/ 4amps per channel output
•
Analog Microphone
•
Headphone with SPDIF jack
•
48-pin QFN ‘Green’ package
Power and Keyboard Controller Item
Specification
Controller
ACPI 2.0
Total number of keypads
99-/100-/103-key keyboard
Windows logo key
Yes
Hotkeys
See “Hot Keys” on page 16.
Battery Specification
Item
6 Cell
Vendor & model name
SANYO/SONY/PANASONIC/SAMSUNG/SIMPLO AS2009A
Battery Type
Li-ion
Pack capacity
4400 mAh
Normal Voltage
2.2 Ah
Package configuration
3S2P
LCD Item
Specification
Vendor/model name
AUO/CPT/CMO/Samsung/LCD/INL
Screen Diagonal (in)
14”
Display resolution (pixels)
1366 x 768 WXGA Clare
Pixel Pitch
0.204 x 0.204
Display Mode
Normal
Typical White Luminance (cd/m (also called Brightness)
220
Contrast Ratio
500 typical
Response Time (Optical Rise Time/Fall Time) msec
8
Luminance Uniformity
1.25 max
2)
22
Electrical Interface
LVDS
Support Color
262K
Viewing Angle (up/down/right/ left)
15/35/45/45
Chapter 1
