Replacing the Keyboard 1. Place the keyboard face down on the Upper Cover. Reconnect keyboard FFCs to the mainboard, and secure the locking latch.
2.
Slide the Keyboard front edge first into the Upper Cover, ensuring that the four locating tabs are correctly seated.
3. Press down as indicated to secure the Keyboard in place.
Replacing the Hard Disk Drive Module 1. Place the HDD in the HDD carrier replace the two (2) screws to secure the carrier.
