2006 Firecat 700
FRONT SUSPENSION SHOCK ABSORBER (Complete Shock Absorber p/n 1703-940) 0740-544 *Not Illustrated
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
4
0603-955 1603-209 0603-910 2603-192 2603-284 2604-413 2604-815 2603-194 0603-540 0603-332 0603-342 0603-349 2603-605 0603-347 0603-389
4 2 1 1 1 1 1 1 2 2 1 1 1 1 1
Bushing, Shock Sleeve, Eyelet Eyelet, Shock Rod, Shock Bumper, Shock Bearing - Assembly Kit, Seal/Rebuild Spacer Washer, Top Out Valve, 0.700 x 0.010 in. Valve, 1.100 x 0.006 in. Valve, 1.300 x 0.008 in. Piston, 0.120 in. - Orifice Valve, 1.250 x 0.010 in. Washer, Backup
16 17 18 19 20 21 22 23 24 25 26 27 28 29 *
0603-301 1 2604-816 1 1604-316 1 1604-425 1 2603-222 1 2603-246 1 2604-840 1 2604-841 1 2603-245 2 2604-897 1 2604-817 1 0703-341 1 1604-318 1 0624-097 1 2639-149 AR
Nut, Lock Piston, Floating Screw, Relief (inc. 19) O-Ring Body, Shock Sleeve, Protector Nut, Adjuster Nut, Locking - Adjuster Retainer, Sleeve Decal, Shock End Cap, Shock (inc. 27-28) Valve, Pressure (inc. 28) O-Ring, Valve Screw, Valve Oil, Gas Shock - 6 qt Case
