2006 Firecat 700
MAGNETO 0739-402
1 2 3 4 5 6 7
3004-378 3006-022 3006-734 3005-433 3004-338 3006-716 3005-987
4 1 1 3 1 1 1
Bolt Base, Stator - Plate Stator Bolt Bolt Rotor/Flywheel Washer
8 9 10 11 12 13
3004-362 3006-476 3004-706 3005-889 3005-960 3005-775
1 1 2 1 1 1
Washer, Lock Bolt Screw Sensor, Ignition Timing Plate, Stator Lead Wire Grommet, Stator Lead Wire
43
