2006 Firecat 700
GAS TANK ASSEMBLY 0740-813
1 2 3 4 5 6 7
0770-625 0510-358 1670-447 1670-511 0670-289 1670-321 0610-017 0610-008 8 1670-523 9 0470-400 10 0610-692 0610-693
24
1 1 1 1 AR 1 AR AR 1 1 AR AR
Tank, Gas (inc. 2-9) Strainer, Gas Tank Cap, Gas Tank (inc. 4) Seal, Gas Tank Cap Tape, Teflon Outlet, Gas Tank Hose, Gasline - 100 ft Hose, Gasline - 25 ft Gauge, Gas w/Seal (inc. 9) Seal, Gas Gauge Hose, Gasline - 25 ft Hose, Gasline - 100 ft
11 12 13 14 15 16 17 18 19 20
1670-166 1 Filter, In-Line Fuel 0123-765 4 Washer, Cup 8041-366 2 Nut, Lock 8011-041 2 Bolt, Carriage 8048-366 2 Nut, Flange 0623-427 4 Nut, Speed 7611-169 1 Decal, Jet Chart 0123-788 AR Cable Tie - 7.5 in. 1623-234 3 Clamp, Hose 8047-366 7 Nut, Flange
