2006 Firecat 700
BELT GUARD ASSEMBLY 0738-673
1 2 3 4 5 6 7
0607-757 0623-855 0607-659 1611-565 3611-969 8047-366 8040-426
1 1 1 1 1 1 1
Guard, Belt Screw, Shoulder Strap, Hold-Down Decal, Warning - Belt Guard Decal, “ACT - Roller Driven Clutch” Nut, Lock Nut, Lock
8 9 10 11 12 13 14
8050-252 1623-046 8017-672 0707-582 0617-450 1611-582 5611-862
1 1 1 2 1 1 1
Washer Washer, Rubber Screw, Machine Retainer, Drive Belt Foam, Belt Guard Decal, Caution - Jetting/Storage Decal, Spring Adjustment
23
