2006 Firecat 700
HEADLIGHT, INSTRUMENTS, AND WIRING ASSEMBLIES 0740-744
1 2 3 4
1686-269 1 Harness, Main 1686-257 1 Harness, Hood 0123-788 AR Cable Tie - 8 in. 0609-530 1 Lens/Reflector - Headlight - Right (inc. 5) 0609-531 1 Lens/Reflector - Headlight - Left (inc. 5) 5 0609-251 4 Bulb, Headlight 6 0623-360 2 Spring, Adjuster 7 1623-025 2 Insert
20
8 9 10 11 12 13 14 15
1623-137 1623-024 0620-292 0620-281 0620-280 0630-181 8020-045 8047-366
2 2 1 1 4 1 1 1
Clip, Hairpin Screw, Adjuster Tachometer/Speedometer (inc. 11-12) Bracket, Retaining Nut w/Washer Regulator, Voltage Screw, Cap Nut, Lock
