2006 Firecat 700
SLIDE RAIL AND TRACK ASSEMBLY (Complete Skid Frame Assembly p/n 7998-909; p/n 7998-910 Black, Orange) 0740-724
1 2 3 4 5 6 7 8 9 10 11 12 13 14
12
2604-887 2 Rail, Formed 0604-930 5 Axle, Inner 1623-248 10 Screw, Cap 2604-281 1 Spacer 8002-043 2 Screw, Cap 8050-217 4 Washer 2604-842 2 End Cap, Slide Rail 8047-366 8 Nut, Lock 0123-859 2 Screw, Machine 2604-543 2 Wearstrip, Slide Rail 0123-767 2 Rivet, Solid 0104-631 2 Pad, Shock 0123-766 2 Nut, Push 8020-132 4 Screw, Cap
15 16 17 18 19 20 21 22 23 24 25 26 27 28
2604-593 4 8047-426 4 8060-633 4 0604-967 4 0604-918 2 8005-676 2 0623-044 2 2604-860 2 2604-046 2 8041-486 2 0704-352 2 8002-042 4 1602-886 1 1602-134 34
Bracket, Mounting - Front Arm Nut, Lock Rivet Bracket, Retaining Pad, Shock Screw, Cap Washer Block, Rear Arm Coupler Bushing, Rear Arm Coupler Nut, Lock Adjuster, Track Screw, Cap Track Assembly (inc. 28) ‹ Clip, Guide
