Functions of and How to Use User Mode (GR-700EXL-1) When the power supply is turned on (i.e. PTO switch ON), the standard number of part-lines of rope corresponding to a work condition is selected.
Selecting Number of Part-lines of Rope [NOTICE] If the registered number of part-lines of rope is smaller than the standard number, a maximum allowable lifting load is limited, depending on the registered number. In case the number is registered as ‘0’, however, a process takes place as if the standard number were registered. Similarly, a process takes place on the basis of the standard number of part-lines of rope if the registered number is larger than the standard number.
Register the number of part-lines of rope using the number of part-lines of rope select key and the register key.
Number of part-lines of rope indicative symbol
Number of part-lines of rope
m
t
max t
Number of part-lines of rope select key
m
Decrease key Increase key
Register key
IW301-0211E15
3. Once the intended number of part-lines of rope is
1. Press the number of part-lines of rope select key.
set, press the register key and register the number. Then, the number of part-lines of rope symbol will be turned off and the jib angle display will return to a normal status.
The number of part-lines of rope symbol will flash, and the number of part-lines of rope will be shown on the jib angle display in a flashing mode. 2. Press the increase or the decrease key to set the number of part-lines of rope at a desired value.
[NOTICE] The number of part-lines of rope can be confirmed by pressing the display alteration key.
[NOTICE] When the increase or the decrease key is pressed, a numeral showing the number of rope stops flashing and becomes continuously marked up, showing a fixed value for the increase or decrease. When the increase or the decrease key is kept pressed, the number of rope continuously increases or decreases.
87
W301-0212E
