Functions of and How to Use User Mode (GR-700EXL-1)
19.Left swing restriction indicator lamp Lights up when the left swing limiting function is activated. 20.Number of part-lines of rope select key Used to register a number of part-lines of rope. Display Panel 2 5 1 3 2 4
2
3
3
2 3
IW301-0231E10
4. Suspension lock state indicative symbol Displays that the suspensions are locked up.
1. Over-front position symbol Indicates that the boom is swung into the over-front position.
5. Boom position indicator
2. Outrigger state indicative symbol
Displays the boom position in 10° increments.
Displays the way the outriggers are extended. Flashes while an outrigger state is being selected and is marked up while it registered. 3. "on-rubber" (Outrigger-not-in-use) state indicative symbol Indicates that the on-rubber operation (non-outrigger operation) is selected. Marked up when the stationary on-rubber operation is selected, and flashes when the traveling on-rubber (creep) operation is selected.
83
W301-0212E
