Functions of and How to Use User Mode (GR-700EXL-1)
17.Boom angle indicative symbol
13.Boom length display
Indicates that the boom angle display (19) displays the boom angle.
Usually displays boom length. Displays the lifting height while the display alteration key is pressed. When the lifting height restriction function is effective, this displays lifting height restriction value while the register key is being pressed.
18.Lower boom angle limit restriction symbol This symbol, while marked up, means the boom angle display (19) displays the registered lower boom angle restricted value.
14.Lifting height indicative symbol
19.Boom angle display Normally displays the boom angle. Displays the moment % when the display alteration key is held down. When the restriction function is activated, the lower boom angle limit restriction value is displayed while the register key is held down.
This symbol, while marked up, means the value in the boom length display (13) is a lifting height. 15.Lifting height restriction symbol This symbol, while marked up, means the value in the boom length display (13) is a lifting height restriction value. The lifting height symbol (14) is marked up simultaneously.
20.Boom lift indicative symbol Is marked up when the boom lift is selected.
16.Upper boom angle limit restriction symbol
21.Single-top lift indicative symbol
Indicates that the jib angle display (1) displays the registered boom angle upper restricted value.
Is marked up when the single-top lift is selected.
