Functions of and How to Use User Mode (GT-550E-1) How to Use the Working Range Limit Function
Boom Angle Limit
[NOTICE]
Raise or lower the boom to the desired angle, and
◆If the selected working range limits allow the crane to approach too close to an obstruction, the crane may be contacted or hit, depending on the operational status and the manner in which the load is handled. When selecting limits, allow sufficient clearance.
press the boom upper or lower limit restriction key. The corresponding limit restriction indicator lamp will flash and the buzzer will sound continuously, indicating that the limit boom angle has been registered in the memory. When the boom is moved back to an angle within the set limit, the limit restriction indicator lamp stops flashing and stays illuminated and the buzzer stops.
The working range restricting function makes the boom automatically stop at the previously registered boom angles (upper and lower), lifting height and radius.
Thereafter, the upper or lower boom angle limit restriction indicator lamp flashes and the buzzer sounds continuously whenever the upper or lower limit previously registered is reached.
If makes the alarm sound when the boom reaches the previously registered swing restriction. The function is useful for handing a load in a
To cancel the boom angle limit function, press the boom angle limit restriction key again. The corresponding boom angle limit restriction indicator lamp will go off.
confined place because it defines the area in which the boom can operate. [NOTICE] ◆Turning the power off (PTO switch: OFF) automatically erases all the previous settings stored in memory after approximately 2 hours. To resume the operation more than 2 hours after the power has been last turned off, enter the settings all over again.
m
Upper boom angle restricted Lower boom angle restricted
t
Lifting height restricted
Upper boom angle limit restriction indicator lamp
max t
m
Lower boom angle limit restriction indicator lamp
u Lower boom angle limit restriction key
H L Load radius restricted
Upper boom angle limit restriction key
Swing restricted IW301-0211E19
R IW301-0211E18
