Functions of and How to Use User Mode (GT-550E-1)
15. Lifting height restriction symbol This symbol, while marked up, means the value in the boom length display-13 is a lifting height restriction value. The lifting height symbol-14 is marked up simultaneously. 16. Upper boom angle limit restriction symbol Indicates that the jib angle display-1 displays the registered boom angle upper restricted value. 17. Boom angle indicative symbol Indicates that the boom angle display-19 displays the boom angle. 18. Lower boom angle limit restriction symbol Indicates that the boom angle display-19 displays the registered lower boom angle restricted value. 19. Boom angle display Normally displays the boom angle. Displays the moment % when the display alteration key is held down. When the restriction function is activated, the lower boom angle limit restriction value is displayed while the register key is held down. 20. Boom lift indicative symbol Comes on when the boom lift is selected. 21. Single-top lift indicative symbol Comes on when the single-top lift is selected.
