Adjustment Value Table Applicable serial No. △ 1 ：545484 ~
Specification No. : GR-700E-1-00101 Specification No. : GR-700E-1-00102 AML model
: AML-L B
AML code No.
: 361-915-70000
AML code No.
: 361-920-20000
1. Setting before adjustment Capacity setting Head-off capacity setting
Jib selection
Single top selection
Winch drum position setting
Not set
Not set
Not set
Set to “R” (rear)
2. Adjustment the detector Precautions for adjustment (*1) Adjust the center of dispersion to coincide to the adjusting value. (*2) Adjust the boom angle and the moment in the elevating lowering operation. (*3) Adjust the swing angle in the clockwise swing operation. (*4) When adjusting the moment, make the number of part-lines of rope to the standard number (four part-lines) that is when boom fully extended, and set the AML as Boom status: Boom and Number of part-lines of rope:4. 1 ：The adjusting value is for 0.47 ton hook installed, and the value in the { } is for 0.85 ton hook installed. Adjustment item
Boom length
Boom angle (*2)
Condition
Tolerance
Zero-point adjustment
Boom length: Fully retracted
11.5m
± 0.04m (± 0.08m for zero-point check)
Span adjustment
Boom length: Fully extended
44m
± 0.04m
Zero-point adjustment
Boom angle: 0°(actual value)
0°
± 0.1° (± 0.2° for zero-point check)
Span adjustment
Boom angle: 80°(actual value)
80°
± 0.1°
Zero-point adjustment
Swing angle1:0°
Swing position : front (Right swing)
Swing angle2:360°
Swing angle (*3) Span adjustment
Outrigger extension width
Adjustment value
Swing angle1:180° Swing angle2:180°
Swing position : rear (Right swing)
± 0.3° (± 0.6° for zero-point check) ± 0.3° (± 0.6° for zero-point check) ± 0.3° ± 0.3°
Zero-point adjustment
Outrigger extension width: MIN.
1.4m
± 0.006m (± 0.012m for zero-point check)
Span adjustment
Outrigger extension width: MAX.
3.6m
± 0.006m
150
W301-0212E
