88 V-MAC Co-Pilot Operator’s Manual Maintenance The MAINTENANCE submenu screen is accessed from the stationary MAIN MENU 2 screen (see) . To view the screens of the MAINTENANCE submenu, highlight “Maintenance” with the stalk switch Up & Down button and then press the Enter ↵ ) button to select the screen. (↵ The MAINTENANCE submenu screen contains the following main screens: Displays the maintenance schedule for various maintenance items, such as engine oil and coolant change. Maintenance items are displayed on the screen one at a time as shown in . Maintenance items, when enabled in VCADS or MACKtraq, can be reset after maintenance has been performed. If maintenance has not been performed, resetting the maintenance item will be prohibited.
Maintenance Monitor
C0035402
Figure 53 — Maintenance Screens
GuardDog™ (optional; must be enabled) GuardDog™, an active maintenance monitoring system, uses sensor readings to show the status of routine maintenance requirements. If the vehicle is equipped with the GuardDog™ system, Co-Pilot will display GuardDog™ related maintenance items under the following conditions:
• When the vehicle is started • During driving as individual maintenance items become due • Manually through the GuardDog™ Status screen After power-up initiation and the MACK LOGO screen appearance, the Co-Pilot will display the ACQUIRING DATA screen. After activation on this screen, if no maintenance item is due, the GUARDDOG™ NO MAINTENANCE ITEMS DUE screen will appear. However, if more than one maintenance item requires service, the GUARDDOG™ MAINTENANCE interrupt screen (see) will appear. To view the due maintenance items, select the GUARDDOG™ STATUS screen.
