Mack Truck Electronic V-MAC IV Vehicle Management & Control with Co-Pilot Display Operator’s Manual

62 V-MAC Co-Pilot Operator’s Manual Instrument Cluster Components The dash cluster consists of the following eight major components: function light indicators, electronic malfunction indicator, engine shutdown indicator, driver information display, low fuel indicator, gauges, speedometer and tachometer, on board diagnostic (OBD) fault and warning indicators. Although not a part of the dash cluster components, but nevertheless part of the dash cluster tool, is the stalk switch (for Co-Pilot® only) located on the right side of the steering column.

The following illustration shows the instrument cluster display (Co-Pilot® shown).

W3036320

Figure 30 — Instrument Cluster Components 1. Function Light Indicators

5. Low Fuel Indicator

2. Electronic Malfunction Indicator

6. Gauges

3. Engine Shutdown Indicator

7. Speedometer and Tachometer

4. Driver Information Display

8. Warning Indicators
