Soot Load Level Action to Take
Level 1
Level 2
Level 3
Level 4
Park the vehicle in a safe location away from overhanging objects (park brake applied). Press and hold the top of the DPF Smart switch momentarily. Allow the DPF regeneration process to complete.
Park the vehicle in a safe location away from overhanging objects (park brake applied). Press and hold the top of the DPF Smart switch momentarily. Allow the DPF regeneration process to complete.
Perform a parked aftertreatment diesel particulate filter (DPF) regeneration IMMEDIATELY to avoid further engine derate and damage to the DPF.
A serious engine problem has occurred. Seek service immediately.
Note: Failure to perform the regeneration will take the Aftertreatment System to Level 2.
Note: Failure to perform the regeneration will take the Aftertreatment System to Level 3.
Note: Failure to perform the DPF regeneration will take the Aftertreatment System to Level 4.
Note: Parked DPF regeneration is no longer possible for the operator.
34 V-MAC Co-Pilot Operator’s Manual
AFTERTREATMENT SYSTEM PARKED REGENERATION (MANUAL)
