102 V-MAC Co-Pilot Operator’s Manual CO-PILOT® OPTIONAL SYSTEMS SCREENS The vehicle management and control (V-MAC) IV system provides optional functions that the driver can access through the Co-Pilot (if available and enabled). The Co-Pilot Optional Systems screens include the following main screens:
• Integrated Temp-A-Start™ (for future support) • Hours of Service (for future support; information not available at time of printing) • Road Connect (optional) • Accuload (for future support; information not available at time of printing) To navigate through the screens, remember the following:
• Use the stalk switch Up & Down button to scroll and highlight an item, scroll to •
the next screen, or enter a value. ↵ ) button to select a screen, enter a value, accept a change or Use the Enter (↵ return to the previous screen.
• Use the ESC button to return to the previous screen. Integrated Temp-A-Start™ (For Future Support) Integrated Temp-A-Start™ (iTAS™) saves fuel by reducing the amount of time spent idling to keep the vehicle’s batteries charged, the engine warm and the cab or sleeper comfortable. Once the optional iTAS™ feature is activated via a dash switch, the system will automatically start and stop the vehicle’s engine. Safety overrides prevent the system from activation if the transmission is in gear, the hood is up or the parking brake is released. iTAS™ voltage and temperature target settings are fully programmable through either VCADS software or, if enabled, via the Co-Pilot display. The iTAS™ submenu screen is selected from the stationary MAIN MENU 2 screen. To view the screens of the iTAS™ submenu, highlight “iTAS” with the stalk switch ↵ ) button to select the screen. Up & Down button and then press the Enter (↵ The iTAS™ submenu screen contains the following screens:
• iTAS Status — Allows the user to view the current status of the iTAS system and to turn on or turn off some of the status items.
• iTAS Settings — Allows the user to set what conditions need to be monitored.
C0035416
Figure 74 — Integrated Temp-A-Start Screens
