5-2 Lower Mechanism: Travel Drive Unit 3 Travel Motor Operator's Manual 1. Foreword This manual provides instruction for handling the swash plate-type piston motor with case rotation type reduction gear for the open circuit MAG-170VP-3800E series. This manual helps first-time users to understand handling issues as well as assists experienced users to review the swash plate-type piston motor with case rotation type reduction gear for the open circuit manufactured by KYB Co., Ltd. Read this operator's manual well and come to an understanding of its contents before operating the motor. It is recommended that users keep this manual ready at hand during operation. This manual mainly explains (1) basic functions and component functions, (2) explanation of component operation, (3) operation procedures, (4) troubleshooting, (5) daily maintenance and inspection of the MAG-170VP-3800E series, swash plate-type piston motor with case rotation type reduction gear for the open circuit. The MAG-170VP-3800E series, swash plate-type piston motor with case rotation type reduction gear for the open circuit produced by KYB Co., Ltd. is the actuator used in the hydraulic unit of the mother machine. Therefore, this operator's manual should be used along with the operator's manual of the mother machine. Always refer to the operator's manual of the mother machine when using this operator's manual.
