4.Sensor Trouble Operation Table

Safety Cautions Be sure to follow the instructions below:

Caution

Do not run the motor beyond the specified range. Doing so may cause damage to the machine.

Never touch the motor within 1 hour after the motor has stopped. The motor surface is very hot as it has been operating. Touching the motor can cause burn injuries.

Caution

Never suddenly remove the oil fill, oil discharge or oil check port of the reduction gear. Doing so may cause the plug to pop out, causing injury. Align the ports to the specified positions, and slowly loosen the plugs, starting from the oil fill port on the top, to release the air inside the reduction gear.

Caution

Top Reduction gear lubricating oil Oil fill port

Reduction gear lubricating oil Oil check port Release air.

Loosen the oil fill port about 2 turns to release air inside the reduction gear.

Bottom Reduction gear lubricating oil Oil drain port Discharge oil.

Discharge oil while slowly loosening the discharge port plug.

Safety Cautions Be sure to follow the instructions below:

When connecting the pipe, make sure that the direction of hydraulic oil flow corresponds to that of the motor rotation. Failure to do so can reverse the motor rotation.

Caution Use specified hydraulic oil only. Otherwise, the machine may be damaged.

Caution Use specified hydraulic oil only. Otherwise, the machine may be damaged.

Caution Do not allow foreign matter to enter inside the motor. Otherwise, the machine will be damaged.

A direction (counterclockwise) C direction (clockwise)

Caution

Caution

Wait until the motor cools down before servicing or inspecting the motor.
