5-2 Lower Mechanism: Travel Drive Unit 13.) Assembling the thrust plate (26) Measure the step between the end surface of the housing (4) and that of the thrust plate (23) using a thrust plate selecting jig, and select the thrust plate (26) according to the table below to assemble it. Step Dimension 1.20 to 0.67 0.66 to 0.04 0.03 to -0.16 -0.17 to -0.41 -0.42 to -0.80
Applicable Thrust Plate 20941-62306 20941-62307 20941-62308 20941-62309 B0841-23017
Note: Assemble the thrust plate (26) by aligning the central hole in the thrust plate with the convex section of the drive gear (25). *1
*1
109
Measuring the step
