5-2 Lower Mechanism: Travel Drive Unit 23.) Removing the planetary gear C (12) Fix the flange (1-1) in place, loosen the bolt (14) and then remove it. Remove the thrust plate (13), planetary gear C (12), needle bearing (11), inner lace (10) and thrust plate (9), in that order. Note: When loosening the bolt (14), follow the instructions below. a.An anti-loosening screw lock agent is applied on the bolt (14). For that reason, ensure that the flange (1-1) is fixed in place. b.When loosening the bolt (14), use a tool with an adequate arm length using an iron pipe, etc. Forcible operation may result in damage to the back or other injury to the operator.
24.) Disassembling the holder C (6) Fix the flange (1-1) in place, loosen the bolt (8) and then remove it. The holder C (6) is fixed in place with the pin (31) on the flange (1-1). Remove the holder C (6) using a press by installing a removal jig from the motor side. Note: When loosening the bolt (14), follow the instructions below. a.An anti-loosening screw lock agent is applied on the bolt (14). For that reason, ensure that the flange (1-1) is fixed in place. b.When loosening the bolt (14), use a tool with an adequate arm length using an iron pipe, etc. Forcible operation may result in damage to the back or other injury to the operator.
93
