2-3 Engine: Assembly and Disassembly [4]
Use a 8-mm wrench to loosen the hosebands (1) in the two locations, and then remove the 2 hoses (2). • Use caps to cover the inter cooler and hoses to prevent the entry of water, dust or dirt.
2 2
1 [5]
Use a 14-mm wrench to remove 4 installation bolts (1), and then remove the inter cooler (2).
2
53
1
