2-3 Engine: Assembly and Disassembly 6 Removal and Installation of Supply Pump Warning
• Be sure to release the hydraulic pressure before beginning work.
Caution
• Be sure to stop the engine before beginning work.
Items to prepare • Wrench (8 mm, 10 mm, 12 mm, 14 mm, 17 mm, 22 mm) • Box wrench (14 mm) • Hexagon wrench (4 mm) • Caps • Plugs • Rags • Cleaning fluid
[1]
Remove the mounting bolt (1) using a 10mm wrench, and remove the cap (2).
2
1 [2]
Adjust the gear until the white mark (2) is aligned with the position (1).
1
33
2
