VIII. SERVICE AND MAINTENANCE Circuit Breakers MOUNTED IN CAB Circuit breakers handle the functions of the heavier duty electrical circuits on the sprayer. They trip when overloaded and automatically reset themselves after they cool down. They will continue to trip and reset as long as the overload or short exists. If the circuit breaker does not reset, replace it with the same amperage breaker only. Correct circuit breaker location and amperage is shown in figure 8.38.
knob (fig. 8.36, item 2), VFC lever knobs (fig. 8.36, item 3), four wheel drive knob (fig. 8.36, item 4), and panel screws (fig. 8.36, item 5). The circuit breakers are located toward the rear of the console.If a circuit breaker does not reset and continues to trip, determine the cause and correct it. MOUNTED ON ENGINE The wire harnesses are protected by circuit breakers mounted on the engine (fig. 5.37). If the
To access the circuit breakers remove the hydrostatic handle (fig. 8.36, item 1), engine throttle
breakers do not reset and continue to trip, determine the cause and correct it. Front and rear cab lights .......40 AMP
5
3 5
4
1
Foam marker and Auxiliary power supplies........ 30 AMP A/C System ...........................30 AMP Starter relay...........................30 AMP
2
Wire harness .........................30 AMP Wire harness .........................50 AMP 5
FIG 8.36
40 AMP BREAKER
30 AMP BREAKER
30 AMP BREAKER
CAB LIGHTS
FOAMER AUX POWER
A/C SYSTEM
MOUNTED ON ENGINE 30 AMP BREAKER
FIG 8.37
30 AMP BREAKER
50 AMP BREAKER
WIRE HARNESS
WIRE HARNESS
FIG 8.38
STARTER
