VIII. SERVICE AND MAINTENANCE Fuses Fuses protect individual lighter duty electrical circuits. They are located toward the rear of the console panel to the right of the operator’s seat (fig. 8.33). If a fuse blows, remove it by rotating the fuse cap counterclockwise as you push down. Then FIG 8.33
pull the fuse straight out (fig. 8.35). Replace each blown fuse with the same amperage fuse
Rinse system, windshield washer (opt), and Traction valve (opt) ................................. 10 AMP Gauges, AM/FM radio, dome light, and C.B. radio................................................ 10 AMP Boom hydraulic controls, tread adjust valve, and Parking brake.......................................... 20 AMP
only. Correct fuse location and amperage is shown in figure 8.34. If the fuse continues to blow, determine the cause and correct it.
Fuel selector switch, boom solution valves, and Seat motor .............................................. 20 AMP Hazard/warning lights, turn signal, and Windshield wiper..................................... 10 AMP
RINSE
GAUGES
BOOM CTRLS
WASHER
AM/FM RADIO
TRD ADJ VLV
TRACT VLV
DOME LIGHT
PRKNG BRAKE
C.B. RADIO
FIG 8.35 FUEL SWITCH
FLASHER
SOL TANK
BOOM SOL VLVS
TURN SIGNAL
SHUTOFF
SEAT
WIPER
VALVES
FIG 8.34
