VIII. SERVICE AND MAINTENANCE FLUIDS Engine oil 1
OIL LEVEL - The engine oil level dipstick is located on the left-hand side of the engine (fig. 8.1, item 1). Never operate the
FILL engine with the oil level below the “L” (low) mark or above the “H” (high) mark. Wait at least five minutes after shutting off the engine to check the oil level; this allows time for the oil to drain to the oil pan. Check the engine oil level daily. CAPACITY - Low to high mark capacity is 2.0 quarts. FIG 8.1
Engine oil pan capacity is 15 quarts. Refer to Engine Operation and Maintenance manual for maintenance schedule.
NOTE: The engine must be level when checking the oil level to make sure the measurement is correct.
Hydraulic Oil Reservoir OIL LEVEL - Check the hydraulic oil level in the reservoir daily (fig. 8.2). Add just enough fluid so the level reaches the bottom tip of the dipstick. Always check the hydraulic oil level FIG 8.2
when it is cool. Hydraulic oil will expand when heated in a system and measuring the reservoir by these levels allows for expansion. TYPE - Premium hydraulic fluids containing high quality rust/ oxidation/and foam inhibitors are required. Hydraulic oil must conform to one of the following types: anti-wear hydraulic oil, type F automatic transmission fluid, or agricultural hydraulic transmission fluid. Replace the oil in the hydraulic reservoir at 500 hours or at the beginning of each spraying season, whichever comes first.
NOTE: Cleanliness is standard: Keep area clean when changing filters and oils.
