V. OPERATING INFORMATION LIGHTS CAB LIGHTS – The front of the cab houses four halogen field lamps (fig. 5.57) and the rear houses two halogen work lamps (fig. 5.56). Locate the light switch on the console panel (fig. 5.54). Rotating the switch clockwise to the first “ON” position (fig. 5.55B) will activate two of the front cab lights. Rotating the switch clockwise to the second “ON” position (fig. 5.55C) will activate the other two front cab lights in addition to the two rear cab lights. The ignition key does not have to be on in order to operate FIG 5.54
any of the cab lights, but extended use without the engine operating to charge the battery is not recommended.
A
B or C
B C
C
FIG 5.55
FIG 5.57
FIG 5.56
55
